GX-2012 Multi Gas Monitor

With the GX-2012, you have multiple tools in one instrument. Having 3 operating modes, the GX-2012 can be used for confined space, safety monitoring in it’s Normal Operating mode; for leak investigation in Leak Check mode; and for underground leak checking in Bar Hole mode. When equipped with an optional TC sensor, the GX-2012 can measure 100% volume methane and dynamically auto range from % LEL to % volume. This is ideal for line purge testing.

As low as $845.00

Benefits:

Versatility: The GX-2012 offers multiple tools in one instrument with three operating modes: Normal Operating mode for confined space and safety monitoring, Leak Check mode for leak investigation, and Bar Hole mode for underground leak checking.

Methane Measurement: When equipped with an optional TC sensor, the GX-2012 can measure 100% volume methane and dynamically auto range from % LEL to % volume, making it ideal for line purge testing.

Compact and Lightweight: The GX-2012 is RKI's smallest personal gas monitor, weighing only 12.3 ounces, making it easy to carry and wear.

Gas Monitoring Capability: It can monitor the standard confined space gases, including LEL combustibles, Oxygen content, Carbon Monoxide, and Hydrogen Sulfide.

Comprehensive Display: The large LCD display provides clear visibility of gas readings, battery level, current time, and automatically backlights in alarm conditions.

Alarm Options: It offers standard alarm types, including vibration, visual, and audible alarms, which can be set to latching or non-latching as per user preferences.

Self-Check and Diagnostics: The GX-2012 continuously checks itself for sensor connections, low battery, circuit trouble, low flow, and calibration errors, ensuring accurate and reliable operation.

Battery Options: The GX-2012 can interchangeably operate on either a Li-ion battery pack or an alkaline battery pack, providing flexibility in power source selection.

Easy Battery Replacement: The batteries are simple to replace and do not require tools to access the removable battery compartment or pack, simplifying maintenance.



Features:

- Monitors ppm LEL, % volume methane, O2, CO and H2S

- 0 to 100% volume methane option

- Auto-ranging display of % LEL and % volume

- 3 Operating modes: Normal, leak check, & bar hole

- PPM leak detector

- Adjustable display ranges

- Visual / audible pulses change with gas concentration

- CO display in leak check mode

- Bar hole test mode for underground leak checks

- Internal sample drawing pump with up to 50′

- Vibration, visual, and audible alarms

- Automatic backlight during alarms

- Lithium ion or alkaline battery packs (interchangeable)

- Intrinsically safe, ATEX/IECEx/CE or CSA/CE (Optional)



Standard Accessories:

- Belt clip

- Rubber nozzle, 3.5”

- Datalogging software

- 10” Probe

- Manual

- Quick reference card

- 10’ Hose

- Training CD



Applications:

- Personal monitoring

- Confined space entry

- Refineries/petrochemical

- Chemical plants

- Hazardous material

- Water/wastewater treatment

- Fire services

- Mining



Datalogging:

10 seconds = 10 hours

5 minutes = 300 hours

10 minutes = 600 hours



Specifications:



Gas Detected Combustible Gases (Methane as standard) % Volume Methane Oxygen (O2) Hydrogen Sulfide (H2S) Carbon Monoxide (CO)
Detection Principle Catalytic combustion Thermal conductivity Galvanic cell Electrochemical cell Electrochemical cell



Gas: Detection Range: Alarm Set Points: Continuous Operation:
Carbon Monoxide (CO) 0-500 ppm



1st 25 ppm
2nd 50 ppm
TWA 25 ppm
STEL 200 ppm
Over 500 ppm



Alkaline battery: 15 hours

Li-Ion battery: 10 hours
70°F (21°C)

Hydrogen Sulfide (H2S) 0-100 ppm



1st 5 ppm
2nd 30 ppm
TWA 10 ppm
STEL 15 ppm
Over 100 ppm



Alkaline battery: 15 hours

Li-Ion battery: 10 hours
70°F (21°C)

Combustible Gases 0-100% LEL



1st alarm 10% LEL
2nd alarm 50% LEL
Over alarm 100% LEL



Alkaline battery: 15 hours

Li-Ion battery: 10 hours
70°F (21°C)

Oxygen (O2) 0-40% Vol



Low alarm 19.5% High alarm 23.5% Over alarm 40.0%



Alkaline battery: 15 hours

Li-Ion battery: 10 hours
70°F (21°C)

% Volume Methane (CH4) 0-100% Vol

No alarms for
% Vol. CH4

Alkaline battery: 15 hours

Li-Ion battery: 10 hours
70°F (21°C)



Alarms:

Alarm  Methods
Gas Alarm : 1st and 2nd, STEL, TWA (user adjustable) and OVER Trouble Alarm : Sensor connection, low battery, low flow, circuit trouble and calibration error
Flashing lights, two tone buzzer, and vibration Flashing lights, trouble displayed, intermittent buzzer, and vibration

Common Specifications:

Sample Method



Internal sample pump, flow rate nominal 0.5 LPM, includes hydrophobic filter



Response Time



T90 in 30 seconds



Datalogging:



10 sec. intervals = 1- hrs. 5 min. intervals = 300 hrs, 10min. intervals = 600 hours



Battery Options



Alkaline battery pack only

Alkaline and Li-Ion battery packs with 100-240 VAC charger

Li-Ion battery pack only with 100-240 VAC charger (Alkaline battery pack not included)

Li-Ion battery pack only with 12 VDC charger (Alkaline battery pack not included)

Alkaline and Li-Ion battery packs with 12 VDC charger

Li-Ion battery pack only with 100-240 VAC / 12 VDC charger

Alkaline and Li-Ion battery packs with 100-240 VAC / 12 VDC charger

Li-Ion battery pack only with no charger



Display



Digital LCD with 7 segments, auto backlight during alarm



Operating Temp. & Humidity



-20°C to +50°C (-4°F to 122°F)
0 to 95% RH, non-condensing



Dimensions



Approx. 143 (H) x 71 (W) x 43 (D) mm (5.6” H x 2.8” W x 1.6” D), approx. 350 g (12.3 ounces)



Case Material



High dust & water resistant design. RFI shielded high impact plastic with protective rubber overmolding



Controls



Five buttons: POWER / ENTER, DISPLAY, AIR, RESET, SHIFT



Power Source



Li-Ion battery pack, or 3 “AA” Alkaline battery pack; interchangeable



Manuals:

- Manual

- Spec Sheet

More Information
Manufacturer RKI Intruments
Description The GX-2012 offers multiple functions in one device with its three operating modes. It can handle confined space safety monitoring in Normal Operating mode, perform leak investigation in Leak Check mode, and conduct underground leak checks in Bar Hole mode. Additionally, with an optional TC sensor, it can measure 100% volume methane and automatically adjust between % LEL and % volume, making it perfect for line purge testing.
Call For Price Yes
4-20 mA Output No
Field Replaceable Sensor No
Min, Max, Avg No
Voltage Output None
Datalogging No
Rechargeable Yes
Field Replaceable Battery Yes
Warranty 1 Year
Audible Alarm Yes
Features The GX-2012 offers multiple functions in one device with its three operating modes. It can handle confined space safety monitoring in Normal Operating mode, perform leak investigation in Leak Check mode, and conduct underground leak checks in Bar Hole mod
Minimum Range Gas Dependent
Mobile Fixed
Standard Range Gas Dependent
Alarms Gas Alarm and Trouble Alarm
Maximum Range Gas Dependent
Sampling Method Fan
Range Gas Dependent
Unit Features

- Monitors ppm LEL, % volume methane, O2, CO and H2S

- 0 to 100% volume methane option

- 3 Operating modes: Normal, leak check, & bar hole

- Adjustable display ranges

- Visual / audible pulses change with gas concentration

Sensor Range

Gas Dependent

- Over 20 Different Gas Variations

Integrated Relays Yes
Sensor Range

Gas Dependent

- Over 20 Different Gas Variations
