K-3510 Copper

K-3510 Copper Kit was designed to obtain Copper levels from 0-1 ppm and 1-10 ppm

Replacement ampoules for the K-3510 Test Kit can be found here.

Copper Information

2-5 Business Days
SKU
k-3510
  $82.50

Description / K-3510 Copper

Why Choose CHEMetrics Chemets kits?

CHEMetrics Chemets self-filing reagent ampoules are a great way to test for dissolved substances in liquids. These visual test kits allow you to obtain results by measuring the color of the sample according to the color comparators provided with the kit. This unique method allows you to attain results quickly and accurately with minimal contact with potentially hazardous materials.

Safe and Reliable Results:

While traditional methods often require multiple steps and thorough preparation, these test kits allow you to obtain dependable results with a few simple steps. By simplifying the testing method, Chemets test kits reduce the potential for operator error. Additionally, each of the ampoules contained in the test kits is vacuum sealed which helps eliminate the problem of obtaining inaccurate results from stale or unstable reagents. These reagents are stored right in the tip of each ampoule and sealed in glass, thereby minimizing direct contact with the chemicals.

What's Included:

     -30 self-filling Ampoules

     -low and high-range comparators

     -1 25 mL Sample Cup

     -Instruction Manual



Method:

The K-3510 Copper Kit was designed to accurately measure the levels of Copper in water from 0-1 ppm and 1-10 ppm. K-3510 uses the Bathocuproine Method. CHEMetrics' test kits employ the bathocuproine reagent. Bathocuproine disulfonate forms an orange-colored chelate with copper. The method measures total soluble copper as ppm (mg/L) Cu. The test kits are applicable for analysis of drinking water, surface waters, groundwater, wastewater and seawater.

Copper is naturally present in the earth's crust and in seawater. Copper-containing fungicides are used to control biological growth in water supplies. The Maximum Contaminant Level Goal for copper is 1.3 mg/L in drinking water.



1. Fill the sample cup to the 25 mL mark with the sample to be tested. 2. Place the Vacu-vial ampoule tip-first into the sample cup. Snap the tip and the ampoule will automatically fill.
3. To mix the ampoule, tilt it from side to side, allowing the bubble to travel from end to end. 4. Dry the ampoule and wait 2 minutes for color development.
5. Place the ampoule into the center of the round comparator and hold it toward a source of light, viewing from the bottom. Rotate the comparator until the color below the ampoule shows the closest match. 6. For higher concentrations, use flat comparator. Place the ampoule between the color standards, moving it along the comparator until you can determine the closest match.



For more detailed instructions, see the link at the bottom of the page.

More CHEMetrics Kits for Copper:

Vacu-Vials
Product Number Method   Range Price
K3503 Bathocuproine   V-2000: 0-12.00 ppm / Spec: 0-7.00 ppm $32.00
Chemets Kits
Product Number Method MDL Range Price
K3510 Bathocuproine 0.05ppm 0-1 & 1-10ppm $67.00



Downloads:

K-3510 Instructions

Safety Data Sheet

Copper Tech Sheet

Copper Information

More Information

Manufacturer CHEMetrics
Gas Copper
4-20 mA Output No
Voltage Output None
Power Requirements 4 AAA Batteries
Datalogging No
Warranty 1 Year
Range 0-1 ppm and 1-10 ppm
