ATI Sensor Ammonia 500-2000 ppm 00-1396
ATI Sensor Ammonia 500-2000 ppm 00-1396
PN - 00-1396, A10-15 Low Range Ammonia Sensor. Replacement sensor for ATI A14/A11and B12 Gas Detectors.
Replaces low range ammonia, can be calibrated for 500 - 2,000 ppm ammonia detection.
- SKU
- ATI 00-1396
$345.00
Related Products
Description / ATI Sensor Ammonia 500-2000 ppm 00-1396
Replacement sensor for ATI A14/A11 and B12 Gas Detectors.
Replaces low range ammonia sensor, 500-2,000 ppm range
Sensor can be installed in existing transmitter and is a simply plug in connection. Sensor must be calibrated on transmitter for proper operation. For information on calibration follow this link, or contact our office.
More Information
| Manufacturer | ATI |
|---|---|
| Gas | Ammonia (NH3) |
| Sensor Type | Electrochemical Cell |
| Range | 500-2000 ppm |
| Accuracy | Generally ±5% of value, but limited by available calibration gas accuracy. |
| Standard Range | 0-1000 ppn |
| Minimum Range | 0-500 ppm |
| Maximum Range | 0-2000 ppm |
| Monitor sensor fits | A14/A11, B12 |
| Sensitivity | 1.0 ppm |
| Operational Temperature Range | -25° to +55°C |
| Operational RH Range | 0-95% non-condensing |
| Warranty | 1 Year |
