ATI Nitrogen Dioxide Replacement Sensor 00-0094

PN - 00-0094, A10-26 Nitrogen Dioxide sensor.  Replacement sensor for ATI A14/A11 or B12 Gas Detectors.

Replaces Nitrogen Dioxide sensor, standard calibration range is 0-20 ppm Nitrogen Dioxide detection.

Nitrogen Dioxide Information

SKU
ATI 00-0094

Customizable Options:

  $225.00

Description / ATI Nitrogen Dioxide Replacement Sensor 00-0094

Replacement sensor for ATI A14/A11 or B12 Gas Detectors.

Replaces Nitrogen Dioxide sensor, 0-20 ppm range

Sensor can be installed in existing transmitter and is a simply plug in connection.  Sensor must be calibrated on transmitter for proper operation.  For information on calibration follow this link, or contact our office.

Nitrogen Dioxide Information

More Information

Manufacturer ATI
Gas Nitrogen Dioxide (NO2)
Sensor Type Electrochemical Cell
Range 0-20 ppm
Accuracy Generally ±5% of value, but limited by available calibration gas accuracy.
Standard Range 0-20 ppm
Minimum Range 0-5 ppm
Maximum Range 0-100 ppm
Monitor sensor fits A14/A11, B12
Sensitivity 0.1 ppm
Operational Temperature Range -25° to +55°C
Operational RH Range 0-95% non-condensing
Warranty 1 Year
