ATI Sulfer Dioxide Sensor 00-0084
PN - 00-0084, A10-27 Sulfer Dioxide sensor. Replacement sensor for ATI A14/A11 or B12 Gas Detectors.
Replaces Sulfer Dioxide sensor, standard calibration range is 0-20 ppm Sulfer Dioxide detection.
- SKU
- ATI 00-0084
Description / ATI Sulfer Dioxide Sensor 00-0084
Replacement sensor for ATI A14/A11 or B12 Gas Detectors.
Replaces Sulfer Dioxide sensor, 0-20 ppm range.
Sensor can be installed in existing transmitter and is a simply plug in connection. Sensor must be calibrated on transmitter for proper operation. For information on calibration follow this link, or contact our office.
More Information
Manufacturer | ATI |
---|---|
Gas | Sulfur Dioxide (SO2) |
Sensor Type | Electrochemical Cell |
Range | 0-20 ppm |
Accuracy | Generally ±5% of value, but limited by available calibration gas accuracy. |
Standard Range | 0-20 ppm |
Minimum Range | 0-5 ppm |
Maximum Range | 0-100 ppm |
Monitor sensor fits | A14/A11, B12 |
Sensitivity | 0.1 ppm |
Operational Temperature Range | -25° to +55°C |
Operational RH Range | 0-95% non-condensing |
Warranty | 1 Year |
