A12 Oxidant Low Range Sensor (00-0264)
E10-XX Low Range Oxidant Sensor only for the A12 Gas Transmitter.
Replaces Bromine, Chlorine, Chlorine Dioxide, Fluorine sensors, standard calibration range is 0-2 ppm for each sensor.
- SKU
- 00-0264
Description / A12 Oxidant Low Range Sensor (00-0264)
Replacement Sensor for the ATI A12 Gas Transmitter.
Replaces Bromine, Chlorine, Chlorine Dioxide, and Fluorine sensors at a standard range of 0-2 ppm. Please note that this sensor need to be calibrated on-site.
If you need the complete Sensing Module (comes calibrated and ready to plug-in), then you need:
00-0211 - Bromine
00-0846 - Chlorine 0-2 ppm
00-0213 - Chlorine 0-10 ppm
00-0215 - Chlorine Dioxide 0-2 ppm
00-0383 - Chlorine Dioxide 0-5 ppm
00-1404 - Chlorine Dioxide 0-1000 ppb
00-0217 - Fluorine
If you need the Sensing Module WITH an Auto-Test Generator, then you need:
00-0212 - Bromine
00-0847 - Chlorine 0-2 ppm
00-0214 - Chlorine 0-10 ppm
00-0216 - Chlorine Dioxide 0-2 ppm
00-0384 - Chlorine Dioxide 0-5 ppm
00-0218 - Fluorine
More Information
| Manufacturer | ATI |
|---|---|
| Gas | Bromine (Br2), Chlorine (Cl2), Chlorine Dioxide (ClO2), Fluorine (F2) |
| Sensor Type | Electrochemical Cell |
| Accuracy | ± 5% of value |
| Standard Range | 0-2 ppm |
| Minimum Range | 0-2 ppm |
| Monitor sensor fits | A12 |
| Sensitivity | 1% of sensor module range |
| Operational Temperature Range | -30º to +55ºC |
| Operational RH Range | 0-95% Non-condensing |
| Warranty | 1 Year |
