GasAlert Extreme O3 0-1 PPM (GAXT-G-DL)
The GasAlert Extreme O3 meter offers protection for workers that come in contact with ozone and will alert them of dangerous levels. This ozone sensor has a range of 0-1 ppm. With its compact size, it makes it easy to wear all day, and the loud audible alarm and lights alert when a high level of ozone is detected. Its internal datalogging (additional accessory needed) allows an industrial hygienist to keep good records. With a concussion-proof boot and long battery life, this ozone monitor gives dependable protection to employees.
GAXT-G-DL has been replaced with the BW Solo O3 - CLICK HERE
- SKU
- GAXT-G-DL
Related Products
Description / GasAlert Extreme O3 0-1 PPM (GAXT-G-DL)
GAXT-G-DL has been replaced with the BW Solo O3 - CLICK HERE
0-1 ppm Ozone (O3) Monitor with a 0.01 ppm resolution.
Along with the benefits and abilities mentioned above, the Gas Alert Extreme also inherits many of the features that you have come to expect as standards from BW:
- Real-time gas concentrations via continuous LCD
- Comfortable to wear due to its compact and lightweight design
- Water Resistant
- Simple, automatic calibration when combined with the MicroDock II Test and Calibration accessory
- Self-Tests on bootup for full-functionality (see table below)
- Bright wide-angled visual alarm bars
- Built-in concussion-proof boot
In addition, features of the GasAlert Extreme monitor family include:
- Vibrating alarm in addition to audible/visual alarms
- Internal datalogging
- Built-in languages include: English, French, German, Spanish, Portuguese
- Passcode protection to prevent tampering
GasAlert Extreme Standard Specifications
| Tests | Sensor integrity, circuitry, battery and audible/visual alarms on activation. Battery (continuous) |
| Pump |
Compatible with the Sampler motorized pump. |
| Typical Battery Life |
1.5 year battery life (typical) with replaceable 3V battery. |
| User Options |
|
| Ratings | EMI / RFI: Complies with EMC Directive 89/336/EEC IP 66/67 |
| Certifications and Approvals |
UL: Class I, DIv. 1, Gr. A, B, C, D American Bureau of Shipping ATEX: CE II 1 G T4 IECEx: Ex ia IIC T4 CE (European Conformity) |
| Warranty | Full two year warranty including sensors (One year NH3, Cl2, ETO, ClO2 sensors) |
Downloads:
More Information
| Manufacturer | Honeywell / BWT |
|---|---|
| Gas | Ozone (O3) |
| Sensor Type | Electrochemical Cell |
| Operational Temperature Range | -4 to +122 F / -20 to +50 C |
| Operational RH Range | 15 - 90 % (non-condensing) |
| Weight | 2.9 oz / 82 g |
| Dimensions | 1.1 x 2.0 x 3.75 inches |
| Alarms | Visual, Vibrating, Audible (95 dB) for Low, High, STEL, TWA |
| Datalogging | Yes |
| Datalogging Note | Datalogging requires accessory |
| Field Replaceable Sensor | Yes |
| Field Replaceable Battery | Yes |
| Warranty | 1 Year |
| Range | 0-1 ppm |
