UV-106MH-NEMA
UV-106MH-NEMA
Medium/High-range UV Ozone Analyzer in an Industrial Enclosure for harsh duty environments.
0-10,000 ppm range
0.1 ppm resolution
0.05 ppm or 2% of reading accuracy
Allows for low range ozone measurement with great accuracy in an industrial enclosure for harsh duty environments.
Rental option HERE
- SKU
- UV-106MH-Nema
Related Products
Description / UV-106MH-NEMA
The UV-106-MH is a medium/high range ozone analyzer featuring ozone measurements up to 1,000 ppm with low range measurement of ozone down to 0.1 ppm.
Industrial Enclosure ozone analyzer is rated for harsh duty environments and is easy to wall-mount. .
Integrated sample pump will pull a sample of ozone from your process or location into the analyzer and measure ozone in that gas stream. A UV lamp and receptor are used to determine the quantity of ozone in gas by determining the rate of ozone absorption by the UV lamp. This method of ozone detection will offer accurate detection of ozone at levels up to 1,000 without compromising low range detection of 0.1 ppm, while eliminating most cross-sensitivity from other gasses.
If you're looking to temporarily monitor ozone, we have a UV-106-MH Ozone Analyzer Rental available here.
Features:
- Industrial enclosure rated for harsh duty environments
- Measurement based on UV absorption
- Accuracy = 0.05 ppm or 2% of reading
- Resolution = 0.1 ppm resolution
- Internal Temperature and Pressure sensors, available in the display
- Internal data logger logs ozone levels, temperature and humidity, 10,000 data points
- Interactive menus includes data averaging options of 10 s, 1 m, 5 m and 1 hr
- User settable ranges, ppb, pphm, ppm, μg m-3, mg m-3
- Internal data obtained via USB and RS-232 output
- Analog output (0-2.5 V and 4-20 mA) of ozone concentration in user-selected units
- Two, two-level relay for control purposes, user-settable set-points
- Long-life pump (15,000 hr)
UV Absorption Technology:
Measuring ozone by UV absorption provides the highest accuracy and reliability in ozone monitoring. Unlike electrochemical or metal-oxide sensors, UV absorption directly measures ozone using its natural absorption of ultraviolet light at 254 nm. This method is absolute, meaning it does not drift, degrade, or require frequent recalibration. As a result, UV analyzers deliver long-term stability and precise readings even in demanding industrial or water-treatment environments.
Sensor-based ozone monitors depend on chemical reactions inside the sensor element. These sensors gradually degrade, drift over time, and are affected by humidity, temperature, and the presence of interfering gases. They require periodic recalibration and sensor replacement—adding cost and reducing measurement certainty. The UV Absorption technology eliminates most all cross-sensitivities from interfering gases in the air.
UV Absorption Technology provides:
- Highest accuracy and repeatability
- No drift and minimal calibration requirements
- Excellent long-term stability
- Minimal, or zero cross-sensitivity from competing gasses in the environment
- Minimal influence from humidity and temperature changes
- Direct, real-time measurement of true ozone concentration
Front of UV-106-MH Ozone Analyzer:
Internal view of UV-106-MH Ozone Analyzer:
Internal view of UV-106-MH Ozone Analyzer:
Datalogging:
Ozone levels are logged internally with onboard datalogging software.
Data can be transmitted from the UV-106-MH via USB or RS-232 directly to your computer. Data is transmitted via a CSV file. Up to 10,000 lines of data can be stored on the device.
- Logged data can include
- Ozone levels
- Temperature
- Date/Time stamp
Internal Sample Pump:
Internal sample pump creates flow through the UV-106-MH Ozone Analzyer. Sample gas flow is measured and can be displayed on the screen to ensure sufficient gas flow is present for accurate ozone measurements.
A flow control valve is built in to adjust flow based on environmental conditions or sample tubing length.
A low-flow status indicator light on the control face of the UV-106-MH will illuminate and indicate a condition where sample flow is insufficient for accurate ozone measurements.
The digital flowmeter and flow control valve are unique features to the 2B product line. These features ensure flow is sufficient for accurate ozone measurements, and any condition outside the requirements creates an alarm or alert to be corrected by the operator.
Ozone Scrubbers:
Internal ozone scrubbers are used to provide zero-gas ozone samples for reference during operation. Ozone scrubbers also eliminate any ozone from the sample stream. Therefore, if ozone samples are pulled into the UV-106-MH no ozone is exhausted from the device, ensuring a safe working space for personnel and equipment.
A zero-gas scrubber is included with the package and provides a tool for manually zeroing the ozone analyzer if necessary.
Calibration:
The UV-106-MH is shipped with a NIST traceable calibration certificate.
Future calibrations of both Span and Zero can be made easily with the user interface.
Inline Filter:
The sample gas drawn into the UV-106-MH should be clean and dry to eliminate interference from dust or humidity.
An inline filter is standard with the Industrial Enclosure to ensure the sample gas is clean and filtered. The Teflon filter disc is replaceable in the canister, allowing filter changes without the need to disconnect the ozone lines.
Replacement filters for the inline filter housing.
Dimensions of the UV-106-MH Industrial Analyzer:
Mounting Options:
OEM Version:
More Information
| Manufacturer | Oxidation Technologies |
|---|---|
| Resolution | 0.1 ppm |
| Sampling Method | Fan |
| Field Replaceable Battery | Yes |
| Warranty | 1 Year |
| Calibration | Annually |
| Range | 0-10,000 ppm |
| Unit Features | - Industrial Enclosure, Water Resistant - Accuracy = 0.05 ppm or 2% of reading - Multi-Channel options avaialble - DewLineâ„¢ for Humidity Control
|
| Sensor Range | 0-10,000 ppm |
| Sensor Range | 0-10,000 ppm |
