GasAlert Extreme PH3 0-5 ppm (GAXT-P-DL)
A durable, reliable gas detector, the GasAlert Extreme series by BW Technologies provide portable, single-gas monitors that are ideal for personnel that need to monitor the air quality of their environment. They are rugged enough for continuous use, but small enough to stay out of the employee's way. The long run-time of the field-replaceable battery, and the ability to replace and calibrate the sensor on-site (with MicroDock II Test and Calibration accessory) decrease downtime that you may experience with other brands. The user-configurable settings (including language, alarm mode, calibration timer, and more) make the Gas Alert Extreme perfect for use in many industries and applications.
GAXT-P-DL has been replaced with the BW Solo PH3 extended- CLICK HERE
- SKU
- GAXT-P-DL
Description / GasAlert Extreme PH3 0-5 ppm (GAXT-P-DL)
GAXT-P-DL has been replaced with the BW Solo PH3 extended- CLICK HERE
0-5 ppm Phosphine (PH3) Monitor with a 0.1 ppm resolution.
Along with the benefits and abilities mentioned above, the Gas Alert Extreme also inherits many of the features that you have come to expect as standards from BW:
- Real-time gas concentrations via continuous LCD
- Comfortable to wear due to its compact and lightweight design
- Water Resistant
- Simple, automatic calibration when combined with the MicroDock II Test and Calibration accessory
- Self-Tests on bootup for full-functionality (see table below)
- Bright wide-angled visual alarm bars
- Built-in concussion-proof boot
In addition, features of the GasAlert Extreme monitor family include:
- Vibrating alarm in addition to audible/visual alarms
- Internal datalogging
- Built-in languages include: English, French, German, Spanish, Portuguese
- Passcode protection to prevent tampering
GasAlert Extreme Standard Specifications
Tests | Sensor integrity, circuitry, battery and audible/visual alarms on activation. Battery (continuous) |
Pump |
Compatible with the Sampler motorized pump. |
Typical Battery Life |
1.5 year battery life (typical) with replaceable 3V battery. |
User Options |
|
Ratings | EMI / RFI: Complies with EMC Directive 89/336/EEC IP 66/67 |
Certifications and Approvals |
UL: Class I, DIv. 1, Gr. A, B, C, D American Bureau of Shipping ATEX: CE II 1 G T4 IECEx: Ex ia IIC T4 CE (European Conformity) |
Warranty | Full two year warranty including sensors (One year NH3, Cl2, ETO, ClO2 sensors) |
Downloads:
.
More Information
Manufacturer | Honeywell / BWT |
---|---|
Gas | Phosphine (PH3) |
Sensor Type | Electrochemical Cell |
Operational Temperature Range | -4 to +122 F / -20 to +50 C |
Operational RH Range | 15 - 90 % (non-condensing) |
Weight | 2.9 oz / 82 g |
Dimensions | 1.1 x 2.0 x 3.75 inches |
Alarms | Visual, Vibrating, Audible (95 dB) for Low, High, STEL, TWA |
Datalogging | Yes |
Datalogging Note | Datalogging requires accessory |
Field Replaceable Sensor | Yes |
Field Replaceable Battery | Yes |
Warranty | 2 Year |
Range | 0-5 ppm |
