Aeroqual Ozone (O3) Sensor Head 0-10 ppm (EOZ)
The Aeroqual 0-10 ppm Ozone Sensor Head is designed to provide accurate, consistent readings of the ozone in your ambient airspace. For high ambient ozone measurement up to 10 ppm the EOZ head is a great option. Response time of 60 seconds allows this to be a good head to find high ozone levels, and measure ozone levels in spaces where testing may be occurring.
Ozone (O3) sensor head. Gas Sensitive Electrochemical (GSE) head will measure Ozone gas from 0-10 ppm with a 0.01 ppm resolution. This is the perfect head for measuring low levels of ozone up to 10 ppm, for testing or high ambient ozone level use.
This sensor uses an active sensor technology with an internal fan to pull air across the GSE sensor at a specific flow rate for accurate gas detection. This fan will pull a fresh gas stream across the GSE sensor every 5 seconds for accurate Ozone detection in most every environment.
The EOZ utilized a Kalman filter to achieve a fast speed of response (4 second update) with good accuracy across a wide range (0-10 ppm). This makes the EOZ a great addition to the ozone gas sensor lines that offer the best accuracy, sensitivity, and stability at low concentrations.
This sensor head will be a direct fit onto any Series-200, Series-300, or Series-500 Aeroqual ozone monitor. This head can be purchased as an addition to your existing monitor, or with a new base unit. To purchase with a base unit see our Aeroqual ozone monitor page. If you currently have an Aeroqual ozone monitor this sensor will be a direct fit for your current monitor. The Series-200, Series-300, or Series-500 will automatically detect this as a 0-10 ppm Chlorine head and react accordingly.
View a brochure with specifications on the Series-200, 300, and 500.
Detailed Sensor Specifications for Aeroqual ambient sensors
|Quickbooks Stock Level||5.000000|
|Call For Price||No|
|Sensor Type||GSS (Gas Sensitive Semiconductor)|
|Maximum Exposure||10.0 ppm|
|Monitor sensor fits||S-200 / S-300 / S-500, Series-900|
|Minimum Detection Limit||0.01 ppm|
|Accuracy||< +/- 10 %|
|Response Time||<5 s|
|Operational Temperature Range||0 to 40 C|
|Operational RH Range||10 to 90%|
