K-8520D Phosphate
K-8520D Phosphate
K-8520D Phosphate Kit is used to determine Phosphate levels from 10-100 ppm.
Replacement ampoules for the K-8520D Test Kit can be found here.
- SKU
- K-8520D
Related Products
Description / K-8520D Phosphate
Why Choose HR CHEMets kits?
HR CHEMets® is the new way to test at high ranges and replaces the now discontinued VACUettes product line. This product's measurement ranges overlaps with the discontinued K-8510D test kit.
Included:
|
- 30 self-filling Ampoules - Flat Comparator - Diluter snapper cup - Micro test tube - Iron activator -Instruction Manual |
Method:
The K-8520D Phosphate, ortho HR CHEMets® Test Kit (10-100 ppm) comes in a plastic case and contains everything needed to perform 30 tests (except distilled water): HR CHEMets® Refill, Flat Comparator, 25 mL sample cup, 3.0 mL syringe, and instructions.
| 1. Using the syringe provided, obtain 2.5 mL of the sample to be tested, and then dispense it into the empty sample cup. | 2. Dilute the contents of the sample cup to the 25 mL mark with distilled water (fig 1). |
 |
 |
| 3. Place the CHEMet ampoule, tip first, into the sample cup. Snap the tip. The ampoule will fill leaving a bubble for mixing (fig 2). | 4. To mix the ampoule, invert it several times, allowing the bubble to travel from end to end. Dry the ampoule. Obtain a test result 4 minutes after snapping the tip. Obtain a test result by placing the ampoule between the color standards until the best color match is found (fig. 3). |
 |
 |
For more detailed instructions, see the link at the bottom of the page.
More CHEMetrics Kits for Phosphate:
| Vacu-Vials | |||
|---|---|---|---|
| Product Number | Method | Range | |
| K8513 | Stannous Chloride | 0-8.00 ppm or 0-5.00 ppm (depending on reader) | |
| K5803 | Vanadomolybdophosphoric Acid | 0-80.0 ppm | |
| Chemets Kits | |||
| Product Number | Method | MDL | Range |
| K8510 | Stannous Chloride | 0.05 ppm | 0-1 & 1-10 ppm |
| K8530 | Vanadomolybdophosphoric Acid | 2 ppm | 2-30 ppm |
| K8515 | Vanadomolybdophosphoric Acid | 5 ppm | 0-120 ppm |
| Vacuettes | |||
| Product Number | Method | MDL | Range |
| K8520D | Stannous Chloride | 10 ppm | 10-100 ppm |
| K8510A | Stannous Chloride | 10 ppm | 0-120 & 120-1200ppm |
| K8510B | Stannous Chloride | 20 ppm | 0-1000 & 1000-10,000ppm |
| K8510C | Stannous Chloride | 200 ppm | 0-30 & 30-300ppm |
Downloads:
More Information
| Manufacturer | CHEMetrics |
|---|---|
| Gas | Phosphate |
| 4-20 mA Output | No |
| Voltage Output | None |
| Datalogging | No |
| Warranty | 1 Year |
| Range | 10-100 ppm |
